2098 ft² Spiral Exchanger

Drawings
Data Sheet
ABSA_Report_(Final_Data_Book_pg_23_24_of_679).pdf
Index_(Final_Data_Book_pg_2_of_697).pdf
Index_(Tag_Specific_Final_Data_Book_pg_2_of_419).pdf
Tranter_SpiralHX_S-2858-2.16_DataSheet.docx
Download

file_download Download All in ZIP

Listing ID: IH-4881
Published

Package ID:
S-2858 2.16
Description

Tranter GmbH horizontal spiral heat exchanger, carbon steel construction, ASME Section VIII Div. 1 stamped, rated for sour gas service per NACE MR0175/ISO 15156. Built new in 2014 for Shell Canada Energy's Carmon Creek Project as a produced water trim cooler. Unit is unused, still in original shipping crate. Heat transfer area 184.0 m² (1,980 ft²).

General Info
Year Built:
2014
Service Type:
Sour
Condition Rating:
A — New, Unpackaged
Condition Details:
On original skidding
Skidded:
No
Housed:
No
Connection Status:
Disconnected
Warranty:
No
Units Available:
1
Exchanger Info
Exchanger Type:
Spiral
Manufacturer:
Tranter GmbH, Schopfheim, Germany
Model #:
2120-E-40480
Length:
2003mm
MAWP:
335psi
Max Temp:
392°F
Heat Surface Area:
2098 ft²
Serial #:
S-2858 2.16
CRN #:
W5688.2
Notes:

Actual Surface Area 2098 ft2
Effective Surface Area 1980 ft2
Weight 60,627 lbs.
Nozzle sizes 6” in/out for one of the fluids and 8” in/out for the other fluid

Data Book pg 398
HS Code 84195000

Financial Info
Availability Status
Deal Pending
Location
Nearest Town / City
Neilburg
Province
SK
Country
Canada
