1,450 hp Waukesha L7042GL Ariel JGK/4 Reciprocating Compressor


1647_drawings.pdf


Listing ID:
IH-4560

General Info
Service Type:
Sweet
PASC Condition Rating:
B
Condition Details:
Field Ready &/or Minor Repair
Skidded:
Yes
Trailer Mounted:
No
Housed:
Yes
Connection Status:
Disconnected
Warranty:
No
Units Available:
1
Compressor Package Details
Year Built:
2006
Packager:
Tormont
Hours:
60548
Hours (Details):
Overhauled @ 39,790 hours
MAWP:
1290
VRU Application:
No
Compressor Details
Compressor Type:
Reciprocating
Compressor Make:
Ariel
Compressor Model:
JGK/4
Throws:
4
Stages:
4
Cylinder Sizes:
(1)26.5", (2)15.875, (3)10.5", (4)6.25"
Driver Info
Driver Make:
Waukesha
Driver Model:
L7042GL
Driver Types:
Natural Gas
Max HP:
1,450 hp
Rated RPM:
1200 RPM
Cooler Info
Cooler Make:
Air-X-Changer
Cooler Model:
156EH
Control Panel
Control Panel Make:
REMVue-500
Building / Skid Info
Building Heated:
Yes
Notes:

=====================

EQUIPMENT OVERVIEW

=====================



For information only, subject to engineering review.



STAGE CONFIGURATION



STAGE / THROW | CYLINDER SIZE | CYLINDER PRESSURE | VVP



Stage 1 / Throw 3 | 26.5” K | 230psig | Yes

Stage 2 / Throw 4 | 15.875” K | 635psig | Yes

Stage 3/ Throw 2 | 10.5” K | 845psig | Yes

Stage 4 / Throw 1 | 6.25” K | 2050psig | Yes



SAMPLE PERFORMANCE



Suction Pressure: 10psi > Discharge Pressure: 900psi > 5.7MMSCFD @ 1430HP (1st stg partial unload)

Suction Pressure: 20psi > Discharge Pressure: 500psi > 7.5MMSCFD @ 1418HP (1st stg partial unload)

Suction Pressure: 23psi > Discharge Pressure: 1000psi > 6.0MMSCFD @ 1397HP (1st stg HEVR)



PACKAGE FEATURES



• Engine is ESM controlled.

• 1200RPM rating.

• Built June 2006.

• This unit was s/d November 28/14 and preserved.

• All electrical is disconnected.

• 60548 total hours with a major overhaul completed March 2013.

• Cooler is Air-X-Changer m/n:156EH Cooler Pressure ratings per stage are: 1st, 215psi.,  2nd, 270psi.,  3rd,645psi.  & 4th, 1290psi.

• Auto/manual louvers.

• Full sound attenuation, including no windows, sound suppressed air inlets and 4 electric roof fans with sound suppression.

• 12 blade cooler fan

• V-ball inlet pressure control

• Auto/manual recycle & blow-down.

• Engine oil & glycol drain/fill systems

• Fuel gas scrubber/filter Toromont 285psi.   s/n: 31658FF     CRN’s;  N4402.23    H9603.1

• Summer/winter engine air inlet

• (4) 24″ x 48″ catadynes

• 3 ton crane

• AC powered lights

• (1) exhaust fans

• (2) gas detection

• (2) fire eyes

• Outside ESD’s



=========================

ADDITIONAL INFORMATION

=========================



Condition:

Field Ready and/or Minor Repair



Manufactured:

Toromont 2006



Location:

Central Alberta



Availability:

1 Week for Disconnection



Service:

Sweet



Driver:

Waukesha 7042GL-ESM



RPM:

1200



HP:

1450 hp



Model (Driven):

Ariel JGK/4



Stage:

4 stage



Cooler:

Air-X-Changer



Control Panel:

REMVue-500 PLC



CRN Registration:

Alberta & Saskatchewan (7/12 vessels are B.C. as well



==========
