Service Type	Sour
Year Built	2000
Diameter	48"
Separator Length	15'
MAWP	1440psi
Position	Horizontal
Phases	3 Phase
PASC Condition Rating	B
Notes	Equipment Overview Newly refurbished in 2020 by Crusader Joint Ventures, this 48” OD x 15’ 1440psi Sour 3 Phase Horizontal Separator Package is ready to be redeployed. Virtual Tour Explore this package in rich detail through a virtual walkthrough below. Vessel V-100 (x1) 48” OD x 15’- 0” S/S x 1440 PSI MAWP HORIZONTAL VESSEL Manufactured in 2000 by Larsen & D’Amico Reconditioned in 2020 by CAPE Manufacturing CRN: L7688.213 A#: 454495 “U” Stamped 1/8” Corrosion Allowance 100°F Design Temperature M.D.M.T.-20°F @ 1440 Psig RT-1 PWHT Designed 3 Phase, Dressed 3 Phase VESSEL CONNECTIONS: N1 Inlet 1 6” NPS CL600 RFWN N2 Gas Outlet 1 6” NPS CL600 RFLWN N3 Water Outlet 1 3” NPS CL600 RFHB N4 Oil Outlet 1 3” NPS CL600 RFHB N5 Drain 1 2” NPS CL600 RFWN N6 a/b Level Cage 2 2” NPS CL600 RFWN N7 PSV 1 2 1/2” NPS CL600 RFHB N8 a/b Bridle 2 2” NPS CL600 RFWN N9 PI 1 1 1/2” NPS CL600 RFWN N10 TI 1 1 1/2” NPS CL600 RFWN M1 Manway 1 20” NPS CL600 RFHB c/w blind & Davit arm Instrumentation LC-1001/2 (x2) NORRISEAL 1001A LEVEL CONTROLLERS Model# 1001A 2" NPT, Sour Service L.H. or R.H. Mount, Direct Snap Acting C/w 1-7/8" x 12" PVC Displacer LCV-1001/02 (x2) CVS E SERIES PRESSURE CONTROL VALVES (Reconditioned) 2" CL600 RF, LCC Body 316 SST Trim 657/667-40 or 45 Actuator, Fail Open or Closed Low Temp, STD as Nace Service LG-1001 (x1) PENBERTHY OR EQUAL LEVEL GAUGE V.L. 7-7/8” 1TM5 Transparent 3/4” NPT, 1750 Psi @ 100°F LG-1002 (x1) PENBERTHY OR EQUAL LEVEL GAUGE V.L. 10-1/4” 1RM7 Reflex 3/4” NPT, 2440 Psi @ 100°F FE-1000 (x1) CANALTA OR EQUAL SENIOR METER RUN (Reconditioned) 6” CL600 RF, Sch. 80, Nace Service Trim Built to AGA 2000 SPEC One (1) 1” CL3000 TOL and One (1) 3/4” CL3000 TOL Downstream 1 1/2 Hour Hydro Test, 100% X-Ray, PWHT, 118” OAL C/w CPA 50E Flanged Type Flow Conditioner FR/PR-1000 (x1) BARTON MODEL 202E, 2 PEN FLOW RECORDER 5 Valve Manifold BPCV-1000 (x1) CVS E SERIES PRESSURE CONTROL VALVE (Reconditioned) 4" CL600 RF, LCC Body 316 SST trim 657/667-45 Actuator, Fail Open or Closed STD as Nace Service PSV-1000 (x1) FARRIS PRESSURE RELIEF VALVE Model 2600 2-1/2" CL600 Inlet x 4” CL150 Outlet Nace Service Trim, WCB Body “J” Orifice. LSHH-1000 (x1) SOR ELECTRIC LEVEL SWITCH Model 1510B 2" NPT 316SST Construction Snap Acting PIT-1000 1 ROSEMOUNT 3051 PRESSURE TRANSMITTER Model# 30541TG5A2B21AC6TR 0 to 1000 Psig PIT-1001 (x1) ROSEMOUNT 3051 PRESSURE TRANSMITTER Model# 30541TG4A2B21AC6 0 to 4000 Psig PI-1001 (x1) WGI OR EQUAL PRESSURE GAUGE Silicone Filled 4” dia. Face x 1/2” NPT Bottom Mount End Connection SS Case and Internals 0 to 1,500 Psi Dual Scale TI-1000 (x1) TREND OR EQUAL TEMPERATURE GAUGE TW-1000 1/2” NPT Back Connection 3” Dial, 9” Stem -40 to 240°F Range - Dual Scale C/w ½” FNPT x ¾” MNPT x 9.25” OAL, 7.5" U, 316 SST Thermowell Building & Skid Specifications SK-100 (x1) SKID BASE, 11’- 0” W X 22’ L 3/16” Checker Plate Two (2) End Rolls, 2” Containment B-100 (x1) SELF FRAMING BUILDING 11’- 0” Wide x 22’-0” Long Shed Style Roof Two (2) 3’-0” x 7’-0” Steel Doors, Check Chain, Panic-Hardware, Lock and Weather-Stripping One (1) Window c/w Screen Two (2) Louvers c/w Screen BH- (x3) CATADYNE 12” x 24” MK BUILDING HEATERS 1080/82/84 Sweet Natural Gas 12 VDC Starting Element with 30’ Cables C/w Grill, Vent Hood, Safety Shutoff, 912 Regulator, Maxitrol Regulator and Thermostat Fuel Gas System PI-1010 (x1) WGI OR EQUAL PRESSURE GAUGE Silicone Filled 4” dia. Face x 1/2” NPT Bottom Mount End Connection SS Case and Internals 0 to 200 Psi Dual Scale PRV-1000 (x1) CVS OR EQUAL PRESSURE REGULATOR 1/4” FNPT Connections Sweet Service Trim 250 Psig MAWP 5 to 35 Spring Range PRV-1001/2 (x2) BELLOFRAM OR EQUAL PRESSURE REGULATORS 1/4” FNPT Connections Sweet Service Trim 250 Psig MAWP 0 to 30 Spring Range Electrical System Other electrical equipment is supplied and installed by others. Drawings Drawings are available in the documents area.
Packager	Larsen & D’Amico

Service Type	Sour
Year Built	2008
Diameter	36"
Separator Length	12'
MAWP	1440psi
Position	Horizontal
PASC Condition Rating	B
Notes	Equipment Overview Newly refurbished in 2020 by Crusader Joint Ventures, this 36”OD x 12’ Sour 1440psi 3 Phase Horizontal Separator Package is ready to be redeployed. Explore the details below or click on the "Additional information" tab to get a high-level spec of the unit. Virtual Tour Explore this package in rich detail through a virtual walkthrough below. Vessel V-100 (x1) 36” OD x 12’- 0” S/S x 1440 PSI MAWP HORIZONTAL VESSEL Manufactured in 2008 by Bromley Mechanical Services Inc. Reconditioned in 2020 by CAPE Manufacturing CRN: U5080.21 A#: 589926 “U” Stamped 1/8” Corrosion Allowance 130°F Design Temperature M.D.M.T.-20°F @ 1440 Psig RT-1 PWHT Designed 3 Phase, Dressed 3 Phase VESSEL CONNECTIONS: N1 Inlet 1 - 4” NPS CL600 RFLWN N2 Gas Outlet 1 - 4” NPS CL600 RFLWN N3 Water Drain 1 - 2” NPS CL600 RFWN N4 Water Out 1 - 2” NPS CL600 RFWN N5 Water LLC 1 - 3” NPS CL600 RFLWN N6 PSV 1 - 3” NPS CL600 RFLWN N7 Oil LLC 1 - 3” NPS CL600 RFLWN N8 Oil Out 1 - 2” NPS CL600 RFWN N9 LDSH 1 - 3” NPS CL600 RFLWN N10 a/b Water LLG 2 - 2” NPS CL600 RFWN N11 a/b Oil LLG 2 - 2” NPS CL600 RFWN N12 TI 1 - 2” NPS CL600 RFWN N13 PI 1 - 2” NPS CL600 RFWN M1 Manway 1 - 18” NPS CL600 RFHB c/w blind & Davit arm Instrumentation LC-1001/2 (x2) NORRISEAL 1001A LEVEL CONTROLLERS Model# 1001A 2" NPT, Sour Service L.H. or R.H. Mount, Direct Snap Acting C/w 1-7/8" x 12" PVC Displacer LCV-1001 (x1) NORRISEAL LIQUID CONTROL VALVE Model # 2220 2" CL600 RF Process Connection, LCC Body 3/8" SST Trim, LCC Body Fail Closed Standard Sour Service LCV-1002 (x1) NORRISEAL LIQUID CONTROL VALVE Model # 2220 2" CL600 RF Process Connection, LCC Body 3/4" SST Trim, LCC Body Fail Closed Standard Sour Service LG-1001 1 QUALITY OR EQUAL LEVEL GAUGE Q5T20 Transparent ½” NPT, 1500 Psi @ 100°F Visual Length 7 7/8”, Nace Service C/w Model 330J Gauge Valves, ¾” x ½” NPT LG-1002 (x1) QUALITY OR EQUAL LEVEL GAUGE Q6R20 Reflex ½” NPT, 2375 Psi @ 100°F Visual Length 9 1/8”, Nace Service C/w Model Q146 Gauge Valves, ¾” x ½” NPT FM-1002 (x1) PRIMARY FLO TURBINE METER FQIT-1002 2” CL600 Process Connections 1/2" Metering 0.75 - 7.5 GPM Capacity C/w Magnetic Pickup C/w NUFLO TOTALIZER MC-III Flow Analyzer Explosion Proof, 4-20mA Output FE-1000 (x1) DANIELS OR EQUAL SENIOR METER RUN (Reconditioned) 4” CL600 RF, Sch. 80, Nace Service Trim Built to AGA 2000 SPEC One (1) 1” CL3000 TOL and One (1) 3/4” CL3000 TOL Downstream 1 1/2 Hour Hydro Test, 100% X-Ray, PWHT, 85” OAL C/w Pin Style Conditioner BPCV-1000 (x1) MANUAL GLOBE BACK PRESSURE CONTROL VALVE 3" CL600 RF Globe Valve, Nace Service PSV-1000 (x1) TAYLOR OR EQUAL PRESSURE RELIEF VALVE Model 8200 2" CL600 Inlet x 3” CL150 Outlet Nace Service Trim, WCB Body “G” Orifice, 1253 Psig Set Pressure PI-1001 (x1) WGI OR EQUAL PRESSURE GAUGE Silicone Filled 4” dia. Face x 1/2” NPT Bottom Mount End Connection SS Case and Internals 0 to 1,500 Psi Dual Scale TI-1001 (x1) MASTER-TEMP 300 OR EQUAL TEMPERATURE GAUGE TW-1001 1/2” NPT Back Connection 3” Dial, 9” Stem -40 to 160°F Range - Dual Scale C/w ½” FNPT x ¾” MNPT x 9.25” OAL, 7.5" U, 316 SST Thermowell Skid & Building Specifications SK-100 (x1) SKID BASE, 10’- 0” W X 18’- 6” L Checker Plate Two (2) End Rolls B-100 (x1) SELF FRAMER BUILDING 10’-0” Wide x 16’-0” Long Shed Style Roof One (1) 3’-0” x 7’-0” Foam Panel Door, Window, Check Chain, Panic- Hardware, Lock, and Weather-Stripping Two (2) Sliding Window c/w Screen Two (2) Louvers c/w Screen BH-1080/82 (x2) CATADYNE 24” x 24” MK BUILDING HEATERS Sweet Natural Gas 12 VDC Starting Element with 30’ Cables C/w Grill, Vent Hood, Safety Shutoff, 912 Regulator, Maxitrol Regulator and Thermostat Manual Valves (x6) 2" CL600 RF RP, Ball Valves, Nace Service (x5) 1" CL3000 NPT RP, Ball Valves, Nace Service (x4) 3/4" CL3000 NPT RP, Ball Valves, Nace Service (x4) 1/2" CL3000 NPT RP, Ball Valves, Nace Service (x5) 1/2" CL6000 NPT, Needle Valves, SS (x1) 2" CL600 RF, Y Strainer, Nace Service Fuel Gas System V-1010 (x1) 8” OD X 36” OAL 150 PSI MAWP FUEL GAS SCRUBBER Mechanical HLSD (Reduces Outlet to 1" NPT) 1/16” Corrosion Allowance -20/200°F Design Temperature Registered in Alberta, BC, Sask. PRV-1010 (x1) FISHER 627 PRESSURE REGULATOR 1" NPT, Body Material: WCC Steel Spring Case Material: Aluminum 1/8" Orifice Aluminum Nylon Disk Spring Range 70‐150 Psi Maximum Inlet Pressure: 2000 Psi PSV-1010 (x1) TAYLOR OR EQUAL PRESSURE RELIEF VALVE Model 8250 1" MNPT Inlet x 1” FNPT Outlet Nace Service Trim, WCB Body “E” Orifice, 150 Psig Set Pressure PI-1000/10 (x2) WGI OR EQUAL PRESSURE GAUGES Silicone Filled 2-1/2” dia. Face x 1/4” NPT Bottom Mount End Connection SS Case and Internals One (1) 0 to 60 Psi Dual Scale One (1) 0 to 200 Psi Dual Scale PRV-1000 (x1) FISHER OR EQUAL 67CFR INSTRUMENT REGULATOR 1/4” FNPT Connections Sweet Service Trim 250 Psig MAWP 0 to 35 Spring Range Electrical System Electrical equipment is supplied and installed by others. Drawings >Drawings available in documents area.
